Access Point Wireless Zyxel NAP102.
Model | NAP102 |
RF Specifications | |
Antenna system | Embedded internal antenna |
Antenna gain | 2.4 GHz 3 dBi; 5 GHz 4 dBi |
Support data rate | • 802.11 a/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps • 802.11n: up to 300 Mbps in MCS15 (40 MHz; GI = 400 ns) • 802.11ac: up to 866 Mbps in MCS9 (80 MHz; 2 spatial streams; GI = 400 ns) |
Receive sensitivity | Min. Rx sensitivity up to to -99 dBm |
Interfaces | |
Number of 10/100/1000M LAN | 1 |
Console port | 4-Pin serial |
PoE | Yes |
PoE power draw | 9 W |
WLAN Features | |
Smart mesh | Yes |
Mesh AP for multiple SSID with VLAN | Yes |
Fast Roaming | Pre-authentication, PMK caching and 802.11 r/k/v |
Wireless Security | |
WPA2-PSK | Yes |
WPA2-Enterprise | Yes |
WLAN access control list | Yes |
EAP types | TLS, TTLS, PEAP, FAST, AKA and SIM |
IEEE 802.1X | Yes |
Number of SSID | 8 (per radio) |
MAC filtering | Yes |
Layer-2 isolation | Yes |
RADIUS authentication | Yes |
Captive portal | Yes |
Network | |
VLANs | Yes |
DHCP client | Yes |
QoS (PG) | |
WMM | Yes |
WMM power save | Yes |
DiffServ marking | Yes |
Management | |
Cloud managed | Yes |
ZON utility | Support |
Smart connect | Neighbor device discovery |
Others | |
Plenum rating | Yes |
Input power | 12 VDC, 1 A |
MTBF (hr) | 1,241,824 |
Physical Specifications | |
Item | Dimensions (WxDxH)(mm/in.) 130 x 130 x 54.7/5.12 x 5.12 x 2.17 Weight (g/lb.) 300/0.67 |
Packing | Dimensions (WxDxH)(mm/in.) 278 x 209 x 72/10.94 x 8.23 x 2.83 Weight (g/lb.) 700/1.54 |
Included accessories | • Power adapter • Wall/Ceiling-mount plate |
Environmental Specifications | |
Operating | Temperature 0°C to 50°C/32°F to 122°F Humidity 10% to 90% (non-condensing) |
Storage | Temperature -30°C to 70°C/-22°F to 158°F Humidity 10% to 90% |
- Xuất xứ: Trung Quốc
- Bảo hành: 36 tháng.
