Thông số kỹ Thuật Patch panel 24 port cat5/cat6 Commscope AMP – 760237040
| Product Classification 760237040 | |
| Portfolio | CommScope® |
| Product Type | Copper patch panel |
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
| Dimensions | |
| Depth, with cable management | 119.38 mm | 4.70 in |
| Diameter Over Dielectric, maximum | 1.168 mm | 0.046 in |
| Diameter Over Dielectric, minimum | 0.762 mm | 0.030 in |
| Height | 44.45 mm | 1.75 in |
| Width | 482.60 mm | 19.00 in |
| Electrical Specifications | |
| ANSI/TIA Category | 5e | 6 | 6A |
| Environmental Specifications | |
| Flammability Rating | UL 94 V-0 |
| Operating Temperature | -10 °C to +60 °C (+14 °F to +140 °F) |
| Safety Standard | cUL | RCM | UL |
| Storage Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| General Specifications | |
| Total Ports, quantity | 24 |
| Cable Type | U/UTP (unshielded) |
| Brand | CommScope® |
| Color | Black |
| Modules, quantity | 0 |
| Package Quantity | 1 |
| Rack Type | EIA 19 in |
| Rack Units | 1.0 |
| Mechanical Specifications | |
| Panel Style | Straight |
| Material Type | High-impact, flame retardant, thermoplastic | Powder-coated steel |
Để cập nhật thông tin giá Cáp Mạng Commscope mới nhất, quý khách hàng vui lòng liên hệ Hotline 0902 553 573 hoặc Fanpage để được hỗ trợ tốt nhất.
