Thiết bị mạng Zyxel WAC6303D-S.
Thiết bị mạng Zyxel WAC6303D-S.| Model | WAC6303D-S |
| RF Specifications | |
| 802.11n/ac premium features | 2.4GHz: 2×2 MIMO with two spatial stream (SU-MIMO) 5GHz: 3×3 MIMO with three spatial stream (SU-, or MU-MIMO) 802.11ac beamforming (transmit beamforming) Maximal ratio combining (MRC) Low End Sensitivity Improvements (LESI) Time Domain Channel Smoothing 20-, 40- and 80-MHz channels PHY data rates total up to 300 Mbps (11n) + 1300 Mbps (11ac) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) Cyclic Delay diversity (CSD) support Maximum Likelihood Demodulation (MLD) support Low Density Parity Check (LDPC) support |
| Typical transmit output power (dBm) | US (FCC) 2.4 GHz: 25 dBm US (FCC) 5 G GHz: 28 dBm EU (ETSI) 2.4 GHz: 20 dBm EU (ETSI) 5 G GHz: 26 dBm |
| Antenna gain | 2.4 GHz: 3 dBi; 2×2 MIMO 5 GHz: 4 dBi 3×3 MIMO |
| Support data rate | 802.11a/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps 802.11n: up to 300 Mbps in MCS15 (40MHz; 2 Spatial Streams; GI=400ns) 802.11ac:up to 1300 Mbps in MCS9 (80MHz; 3 Spatial Streams; GI=400ns) |
| Receive sensitivity | Min. Rx sensitivity up to -103 dBm |
| Interfaces | |
| Number of 10/100/1000M LAN | 2 x switch ports |
| Console port | 4-Pin serial |
| Input power requirements | Direct DC power or Power over Ethernet (PoE) |
| PoE | 802.3at (full mode) 802.3af (Restrict 2.4G & 5G radio to one transmit stream only.) |
| PoE power draw | 16.2W (802.3at PoE) |
| WLAN | |
| WLAN maximum throughput | Up to 1600 Mbps |
| Fast roaming | Pre-authentication and PMK caching |
| Wireless Security | WPA/WPA2-PSK WPA/WPA2-Enterprise WLAN access control list EAP type IEEE 802.1X MAC filtering Web authentication *3 Layer-2 isolation RADIUS authentication Microsoft AD authentication*3 LDAP authentication *3 MAC authentication *3 Rogue AP detection |
| Number of SSID | 16 |
| QoS | WMM WMM power save U-APSD DiffServ marking |
| Network WAC6303D-S | |
| IPv6 support | Yes |
| VLANs | Yes |
| DHCP client | Yes |
| Management WAC6303D-S | |
| Operating mode | Nebula Cloud managed Controller-managed Standalone |
| ZON Utility | Discovery of Zyxel switches, APs and gateways Centralized and batch configurations IP configuration IP renew Device factory reset Device reboot Device locating Web GUI access Firmware upgrade Password configuration One-click quick association with Zyxel AP Configurator (ZAC) |
| Smart Connect | Neighbor device discovery One-click remote management access to the neighboring Zyxel devices |
| Zyxel AP Configurator | Batch AP configuration Batch AP firmware upgrade Batch AP profile backup |
| Zyxel Wireless Optimizer | WiFi AP planning WiFi coverage detection Wireless health management |
| Standalone AP mode | Yes |
| Managed AP mode | Yes |
| CLI | Yes |
| SNMP | v2c/v3 |
| Physical Specifications and others WAC6303D-S | |
| Item | Dimensions (WxDxH)(mm/in.) 211 x 223 x 39 / 8.31 x 8.78 x 1.54 Weight (kg/lb.) 800/1.76 |
| Packing | Dimensions (WxDxH)(mm/in.) 251 x 247 x 55 / 9.88 x 9.72 x 2.17 Weight (kg/lb.) 1040/ 2.29 |
| Included accessories | Wall/ceiling mount plate |
| Plenum rating | Yes |
| Kensington lock support | Yes |
| Power supply | Input: AC 100-240V, 50~60Hz Output: DC +12V 2A (Sold separately) |
| MTBF (hr) | 3,960,217 |
| Environmental Specifications | |
| Operating | Temperature -20°C to 60°C / -4°F to 140°F Humidity 10% to 90% (Non-condensing) |
| Storage | Temperature -40°C to 70°C / -40°F to 158°F Humidity 10% to 90% |
- Xuất xứ: Trung Quốc
- Bảo hành: 36 tháng.
